Soundproofing
Class A, 30 dB DS,A reduction
Speech level reduction DS,A (dB) is measured using ISO 23351-1. The pod can be placed next to workspaces without compromising privacy.
Sound Masking
Framery Office Sound Masking System™
A pre-fitted sound masking system improves the soundscape of the office outside the pods with an effective radius of 5 m / 16 ft.
Ventilation
Maximum airflow: 53 l/s, 112 CFM (191 m³/h).
Default airflow: 31 l/s, 65 CFM (111 m³/h) when in use. After use, the pod refreshes itself with a higher ventilation speed.
Standby mode: 24 l/s, 51 CFM (86 m³/h).
Adjustable directional airflow: Choose between direct and indirect airflow.
Lighting
Double ceiling light: Color temperature 4000K, illuminance up to 375 lux on the table top.
Video light: Color temperature 4000K, illuminance up to 500 lux on the user’s face.
Pre-set lighting modes: Standard mode and Video call mode. Lighting can also be adjusted manually.
Presence Detection
Sensor technology: mmWave radar.
Dimensions
Exterior (with air filter housing): 232.9 x 196.4 x 129.2 cm / 91.7 x 77.4 x 50.9 in (h, w, d).
Interior: 209.7 x 176.6 x 118 cm (h, w, d).
Doorway: 209.7 x 96.6 cm / 82.6 x 38 in (h, w).
Weight: 488 kg / 1076 lb.
Threshold: 1.25 cm / 0.5 in.
Door swing angle: 180°.
Touchscreen Location
On the table.
Connectivity
Framery smart pods gather anonymous occupancy data, measuring when and how often spaces are used. Users in the space cannot be identified and no personally identifiable data is collected. The anonymous data is transferred via built-in 4G connectivity, or through a Wi-Fi connection, and compiled and shown in the Framery Connect platform.
WLAN: Wi-Fi 802.11 a/b/g/n/ac, 2.4 & 5 GHz.
Materials
Exterior
Exterior panels: Powder coated matt steel panels.
Frames: Structure matt black aluminum.
Door frame: Structure matt black aluminum.
Glass: Sound control laminated glass (4 + 4 mm / 0.16 + 0.16 in).
Chassis: Light steel and PET sound-absorbing structure.
Handle: Custom-designed black metal.
Interior
Interior panels: PET sheets laminated with recycled polyester fabric.
Upholstery fabric: Gabriel Tonal.
Carpet: Antistatic and stain resistant low loop pile carpet.
Table: Table top is birch plywood laminated with white, black anti-fingerprint, oak or walnut veneer.
Table leg: Smooth black adjustable table leg or structure black metal fixed table leg.
Furniture Dimensions
Table: 116.8 x 60.0 cm / 46.9 x 23.6 in (w, d).
Table height: Fixed desk: 70 cm / 27.6 in. Height-adjustable desk: 68.7-118.7 cm / 27-46.7 in.
Max load for the table: 60 kg / 132.3 lb.
Optional Accessories
Dual-monitor stand: Includes single monitor support (up to 40″) by default. Optional dual-monitor upgrade available (supports two screens up to 27″ in landscape or portrait orientation).
Privacy film: Add Framery’s privacy film to the glass surfaces of the pod for visual privacy. Requires professional installers.
Framery Room Display kit: Add Framery Room Display outside your smart pod with our full kit: exterior tablet mount, tablet holder and tablet. Same as Smart Pod Kit in Smart Office portfolio.
Smart lock: Locking capability with different entry methods.
Kickplate: Protects interior panel from scuffs and everyday wear. Size: 38 x 54 cm / 15.0 x 21.3 in. (Deliveries start in March 2027.)
Power and Other
Power
Power consumption: Default settings 48.5 W. Highest settings 101 W. Standby mode 14.2 W.
Input: 230 VAC, 10 A*, 60 Hz.
Output AC (power outlet): 120-230 VAC, 6 A, 60 Hz.
Output USB-C PD charge port: 140 W.
Outlets: 2 x on-table power outlets, 3 x under-table power outlets. Optional: 2 x USB-C PD charge ports (140 W), 1-2 x LAN port (with cable).
Door Handedness
Left-handed by default (cannot be changed).
Movability
Relocate the pod without the need for disassembly by adding casters with a movability kit. The kit is reusable. Multiple pods can be moved with one kit.
Safety
Fire Safety
No fire hazardous materials are used in Framery pods. The fire safety of all surface materials, upholstery and acoustics materials of our products are tested and classified by either national or international standards. Framery provides additional safety measurements to adhere to local regulatory requirements.
Seismic Safety
Framery pods comply with seismic testing in accordance with ASCE 7-16 and are designed for easy floor anchoring.
